Quick Brackets
Standard Brackets
Standard Couplings
Adjustable
Type 5750 can easily be adjusted to various dimensions
of valves ranging from 42 mm - 87 mm in height. F03 -
F10 (ISO 5211 top / bottom flange).
Easy mounting
Type 5750 has an uncomplicated construction and is
therefore very easy to mount even with pneumatic tools,
just separate the top part from the bottom part.
Easy maintenance
Type 5750 requires no tools for maintenance.
Safety
During maintenance it is easy to click of the actuator
making sure that the valve can not be activated uninten-
tionally - simply pull the two splits outwards and lift the
actuator incl. the attached top part of the bracket.
Easy mounting
Type 5700 has an uncomplicated construction and is therefore very
easy to mount.
No maintenance
Type 5700 requires no maintenance.
Heavy-duty
Type 5700 has a robust design and is made of AISI 304.
Brackets & Couplings
All couplings are made to fit both bracket type 5700 size 1 - 4 and bracket type 5750
(Quick Brackets) size 1 - 4.
No maintenance
Type 580 requires no maintenance.
Heavy-duty
Type 580 has a robust design and is made of AISI 304.
